Frameset

  • FRAME

    Alloy 27.5" step through frame with smooth welding. Integrated rear rack, fender mounts, Electronic Access Port. Removable battery with security lock.

  • FORK

    Aluminum alloy fork

  • BIKE WEIGHT

    29kg

  • WEIGHT CAPACITY

    135kg

Drivetrain

  • SHIFTERS

    SHIMANO 8-speed rapidfire

  • CRANK SET

    PROWHEEL, 46T

  • CHAIN

    KMC Z7

  • REAR DERAILLEUR

    SHIMANO Altus 8 speed

  • CASSETTE

    SHIMANO 8-speed 12-32T

Components

  • HANDLEBAR

    Alloy bird type bar

  • GRIPS

    Non-slip, shock-absorbing with Alloy ring

  • STEM

    Alloy stem

  • SEATPOST

    Alloy 27.2mm with quick release (350mm)

  • BRAKE

    hydraulic disc brake

  • ROTORS

    160mm

Wheels

  • TIRES

    KENDA 27.5” x 2.10”

  • RIMS

    27.5”

Electric Technology

  • MOTOR

    BAFANG, RM G020.500.DC, 48V/500W

  • CONTROLLER

    48V/500W/18A

  • BATTERY TYPE

    LG, 48V, 12.8Ah, Lithium

  • BATTERY CAPACITY

    5000 mAh

  • RANGE

    Up to 100km subject to ambient temperature, rider weight and ride style

  • POWER ASSIST

    5 Levels of power assisted pedaling

  • THROTTLE

    KAHUA, EA10 thumb throttle 36V

  • BATTERY CHARGER

    48V Smart charger, LED status, with CE certificate

Accessories (included)

  • Display

  • Front & Rear LED Lights

  • Front & Rear Fenders

  • Rear Integrated Cargo Rack

  • Kickstand

  • Pedals
