• RIDER HEIGHTS

5’2’’ to 5’9’’

• FRAME

Alloy 27.5" step through frame with smooth welding. Integrated rear rack, fender mounts, Electronic Access Port. Removable battery with security lock.

FORK

Alloy suspension fork, with hydraulic lock

BIKE WEIGHT

29kg

WEIGHT CAPACITY

135kg

• Drivetrain

SHIMANO 8-speed rapidfire

CRANK SET

PROWHEEL, 46T

CHAIN

KMC Z7

REAR DERAILLEUR

SHIMANO Altus 8 speed

CASSETTE

SHIMANO 8-speed 12-32T

Components
HANDLEBAR

Alloy bird type bar

GRIPS

Non-slip, shock-absorbing with Alloy ring

STEM

Alloy stem

SEATPOST

Alloy 27.2mm with quick release (350mm)

BRAKE

TEKTRO, HD-E3520, hydraulic disc brake

ROTORS

160mm

• Wheels

CST 27.5" x 2.4"

RIMS

Alloy 27.5"

• Electric Technology

MOTOR

BAFANG, RM G020.500.DC, 48V/500W

CONTROLLER

48V/500W/18A

BATTERY TYPE

SAMSUNG, 48V, 15AH, Lithium battery, removable with security lock

BATTERY CAPACITY

5000 mAh

RANGE

Up to 130km subject to ambient temperature, rider weight and ride style

POWER ASSIST

5 Levels of power assisted pedaling

THROTTLE

KAHUA, EA10 thumb throttle 36V

BATTERY CHARGER

48V Smart charger, LED status, with CE certificate

• Accessories (included)

Display

Front & Rear LED Lights

Front & Rear Fenders

Rear Integrated Cargo Rack

Kickstand

Pedals
